Amplla Shield ST Black
A fire extinguisher with a protective shield of coloured plastic in deep gloss black. While you extinguish, the shield protects you from flames, heat and falling debris.
Amplla Shield ST is a fire extinguisher behind a smooth lacquered shield — all you see on the wall is a quiet, continuous surface. Inside works a certified EN3-7 dry powder extinguisher (21A, 113B, C) with a pressure-steel vessel and ABC powder. Deep gloss black finish, single wall mount. A design fire extinguisher for apartments, offices and interiors — no cabinet needed to hide it.
View in 3D
Tap to rotate the device and view it from every angle.
Want to see it in your own room?
- Pick up your phone or tablet.
- Open this page on it.
- Tap “Try it on your wall”.
Parts overview
TECHNICAL SPECIFICATION
P21 - TI62P4VSS
P34 - TI62P6VSS
P21 - ~ 11,4 kg
P34 - ~ 13,2 kg
diameter 630 +/- 2 mm
width 91 +/- 2 mm
-30°C to +60°C
powder - Furex ABC Spezial
P21 - 4 kg
P34 - 6 kg
P21 - 14,1 +/- 2,1 s
P34 - 19,6 +/- 2,9 s
chrome-plated brass - M45x1.5
Working 15 bar
Maximum permitted 17.0 bar
Test 25 bar
202-173-B-00512-22
1015-PED-B-00531-22
202-173-B-01277-22
1015-PED-B-01279-22
P21 - 21A, 113B, C
P34 - 34A, 183B, C
solids, liquids, gases and live equipment up to 1,000 V from a minimum distance of 1 m
7,2 l
nitrogen - N2
alloy steel - P265GH
ABS - red
ČSN EN 3-7+A1:2008
ČSN EN 3-8:2007+OPR1:2008
ČSN EN 3-10:2010
P21 or P34?
Both variants share the same dimensions and differ in charge and extinguishing capacity. The P21 holds 4 kg of powder and rates 21A — the usual choice for flats and smaller spaces. The P34 holds 6 kg and rates 34A, aimed at houses and larger areas; it is slightly heavier and discharges for longer.
Certificates and declarations of conformity for individual countries are available on the Certifications page.
3D and 2D models for design software
Models of extinguishers and mounts to download for architects and designers. Formats for the usual design packages, free and without registration.
View 2D and 3D models
